Variantes
| Références |
d1
métrique |
Diamètre nominal du filetage
métrique |
P
mm |
l1
mm |
Pas de filetage mm |
l2
mm |
d2
mm |
a
mm |
l3
mm |
Type de fil |
Core-Ø |
Sens de coupe | Prix
HTVA |
|---|
| 135030 M10 |
M10 |
M10 |
1.5 |
100 |
1.5 |
24 |
7 |
5.5 |
8 |
M |
8.5 |
rechts | 33,80 € |
| 135030 M12 |
M12 |
M12 |
1.75 |
110 |
1.75 |
28 |
9 |
7 |
10 |
M |
10.2 |
rechts | 40,70 € |
| 135030 M14 |
M14 |
M14 |
2 |
110 |
2 |
30 |
11 |
9 |
12 |
M |
12 |
rechts | 57,55 € |
| 135030 M16 |
M16 |
M16 |
2 |
110 |
2 |
32 |
12 |
9 |
12 |
M |
14 |
rechts | 61,45 € |
| 135030 M18 |
M18 |
M18 |
2.5 |
125 |
2.5 |
34 |
14 |
11 |
14 |
M |
15.5 |
rechts | 87,25 € |
| 135030 M20 |
M20 |
M20 |
2.5 |
140 |
2.5 |
34 |
16 |
12 |
15 |
M |
17.5 |
rechts | 90,20 € |
| 135030 M22 |
M22 |
M22 |
2.5 |
140 |
2.5 |
34 |
18 |
14.5 |
17 |
M |
19.5 |
rechts | 135,20 € |
| 135030 M24 |
M24 |
M24 |
3 |
160 |
3 |
38 |
18 |
14.5 |
17 |
M |
21 |
rechts | 127,40 € |
| 135030 M27 |
M27 |
M27 |
3 |
160 |
3 |
38 |
20 |
16 |
19 |
M |
24 |
rechts | 167,90 € |
| 135030 M3 |
M3 |
M3 |
0.5 |
56 |
0.5 |
11 |
2.2 |
|
|
M |
2.5 |
rechts | 24,85 € |
| 135030 M30 |
M30 |
M30 |
3.5 |
180 |
3.5 |
45 |
22 |
18 |
21 |
M |
26.5 |
rechts | 206,30 € |
| 135030 M36 |
M36 |
M36 |
4 |
200 |
4 |
56 |
28 |
22 |
25 |
M |
32 |
rechts | 314,50 € |
| 135030 M4 |
M4 |
M4 |
0.7 |
63 |
0.7 |
13 |
2.8 |
2.1 |
5 |
M |
3.3 |
rechts | 24,85 € |
| 135030 M5 |
M5 |
M5 |
0.8 |
70 |
0.8 |
16 |
3.5 |
2.7 |
6 |
M |
4.2 |
rechts | 26,35 € |
| 135030 M6 |
M6 |
M6 |
1 |
80 |
1 |
19 |
4.5 |
3.4 |
6 |
M |
5 |
rechts | 27,75 € |
| 135030 M8 |
M8 |
M8 |
1.25 |
90 |
1.25 |
22 |
6 |
4.9 |
8 |
M |
6.8 |
rechts | 30,30 € |
|
